Specification & Technical Parameters:

Model			KCOC-20P	KCOC-25P	KCOC-32P	KCOC-40P	KCOC-50P	KCOC-65P
Cooling capacity	(kcal/h)		50000	60000	80000	100000	120000	160000
	(W)		58000	70000	93000	116000	140000	186000
Oil temperature range	℃		Adjustable temperature from 20 to 50 degrees Celsius
Usage conditions	Environmental requirements	℃	5~43℃, well-ventilated, free from dust and corrosive mists, protected from direct sunlight and rain, heat radiation, and vibration.
	oil temperature	℃	15~50
	Oil types		Hydraulic oil, lubricating oil
	oil viscosity	Cst	20~100
Main power supply		V	3PH/AC380V±10%/50Hz
Oil-free pump input power		kW	19.7	24.2	30	48.4	50.6	60
Oil pump input power		kW	25.2	29.7	37.5	59.4	61.6	75
Input current for oil pump		A	48	53	75	107	112	145
compressor input power		kW	18.1	22.5	25.8	42.4	42.4	51.6
oil pump	Input power	kW	5.5	5.5	7.5	11	11	15
	flow	L/min	200	263	315	400	526	630
Interface dimension (flange)		mm	DN80×80	DN80×80	DN100×100	DN125×125	DN125×125	2-DN100×100
External pipe inner diameter		mm	DN80	DN80	DN100	DN125	DN125	DN150
External dimensions	Width	mm	1000	1100	1100	1100	1100	2200
	thick	mm	1900	2000	2200	2200	2800	2200
	high	mm	1900	2000	2150	2280	2180	2167
weight		kg	700	800	1000	1200	1600	2000
refrigerant		R410A
Protective devices		Refrigerant high/low voltage protection, overload/short circuit/delay protection, power phase loss/reverse phase protection.

Notes:

• Cooling capacity refers to the cooling output under the conditions of an ambient temperature of 35℃, an inlet oil temperature of 40℃, and the use of 46# hydraulic oil;
• This series of units includes: Fixed Temperature Type A, available for selection only;
• This series of units includes: Type A without pump and oil tank, and Type P with pump but without oil tank, available for selection only;
• During installation, a space of at least 100cm must be maintained at the air intake, and a space of at least 300cm must be maintained at the hot air exhaust outlet.
