Specification & Technical Parameters:

Model			KCLD-0.5P	KCLD-1P	KCLD-1.5P	KCLD-2P	KCLD-3P
Cooling capacity		kcal/h	1500	2500	3500	4500	6000
		W	1740	2900	4000	5200	7000
water temperature range		℃	Temperature-fixed type: 15~30℃; Room temperature synchronized type: Room temperature ±△T (△T=1~3℃)
Ambient temperature		℃	5~43
Types of cooling water		–	Clean water, purified water, tap water, mixed water (containing preservatives and additives)
Main power supply		V	1PH/AC220V±10%/50Hz
Total power		kW	0.9	1.5	1.8	2.3	2.5
Total current		A	5	7.8	9.1	11.5	13.5
water pump flow rate		L/min	5	10	12	15	20
Water pump head		m	25
Water tank capacity		L	13	13	13	16	27
Interface dimensions (internal thread)		inch	G¹/₂“	G¹/₄“	G¹/₄“	G¹/₄“	G¹/₄“
External dimensions	Width	mm	470	470	470	520	550
	thick	mm	670	670	670	670	730
	high	mm	832	832	832	832	972
weight		kg	60	70	80	100	130
refrigerant		R410A
Security Protection		Refrigerant high/low voltage protection, overload/short circuit/delay protection, power phase loss/reverse phase protection, and freeze protection.

Notes:

• Cooling capacity refers to the cooling output at an ambient temperature of 35℃ and an outlet water temperature of 25℃;
• The lower limit temperature for both the temperature-fixed and room-temperature-adjustable types is 15℃;
• When installing the chiller, a space of at least 50cm should be reserved at the air inlet, and a space of at least 150cm should be reserved at the air outlet;
• Our products are constantly being improved, and the specific structural dimensions may differ from the parameters above;
• The specifications listed in the parameter table are common models. Our company accepts special orders from customers.
