Specification & Technical Parameters:

Model			KCLD-20P	KCLD-25P	KCLD-32P	KCLD-40P	KCLD-50P	KCLD-65P
Cooling capacity		kcal/h	50000	60000	80000	100000	120000	160000
		W	58000	70000	93000	116000	140000	186000
water temperature range		℃	Temperature-fixed type: 15~30℃; Room temperature synchronized type: Room temperature ±△T (△T=1~3℃)
Ambient temperature		℃	5~43
Types of cooling water		–	Clean water, purified water, tap water, mixed water (containing preservatives and additives)
Main power supply		V	3PH/AC380V±10%/50Hz
Total power		kW	21.6	26.1	32.6	51.9	54.6	65.5
Total current		A	40.7	45.7	62.4	91.5	95.5	126
water pump flow rate		L/min	160	200	266	320	400	532
Water pump head		m	25	25	25	25	25	25
Water tank capacity		L	250	310	400	500	500	700
Interface dimensions (internal thread)		inch	G2″(internal thread)	G2″(internal thread)	DN65 (flang)	DN65 (flang)	DN65 (flang)	DN80 (flang)
External dimensions	Width	mm	1000	1100	1100	1100	1100	2200
	thick	mm	1900	2000	2200	2200	2800	2200
	high	mm	1900	2000	2150	2280	2180	2150
weight		kg	650	750	950	1150	1400	1800
refrigerant		R410A
Security Protection		Refrigerant high/low voltage protection, overload/short circuit/delay protection, power phase loss/reverse phase protection, and freeze protection.

Notes:

• Cooling capacity refers to the cooling output at an ambient temperature of 35℃ and an outlet water temperature of 25℃;
• The lower limit temperature for both the temperature-fixed and room-temperature-adjustable types is 15℃;
• When installing the chiller, a space of at least 100cm should be reserved at the air inlet, and a space of at least 300cm should be reserved at the air outlet;
• Our products are constantly being improved, and the specific structural dimensions may differ from the parameters above;
• The specifications listed in the parameter table are common models. Our company accepts special orders from customers.
